EB12LB-4 EB Series Transducerized Nutrunner

Product description :

EB12LB-4 Lever Start Corded Nutrunner With The Following Features: - Rated For 0.4 - 4 NM With A Recomended Working Range Of 0.8 - 3.2 NM - 112-1114 RPM - 2 lb Tool Weight - Straight Output - Transducer Controlled With Cm ≥ 3.0, Cmk ≥ 2.67 with +/- 15% single-joint torque scatter capability at 100% rated torque - Direct Drive - Lever Start handle

Download 3D Drawings

Download 2D Drawings

Corded

Power Source

Cm ≥ 3.0, Cmk ≥ 2.67 with +/- 15%

External Torque Scatter Rating

Brand

Transducer

Torque Measurement

Direct Drive

Drive Type

Lever Start

Handle Type

Output TypeStraight

Recommended Working Range0.8 - 3.2 NM

Useful Tool Range0.4 - 4 NM

Max Torque4.0

Min Speed (RPM)112.0

Max Speed (RPM)1114.0
